Technical specifications
Vehicle type
Electric bike
Voltage
36 V
Power
630Wh
Width
85 mm
Height
62 mm
Depth
412 mm
Weight
3.2 kg
Warranty
2 years
Ean13
5608554018509
Description
TECHNICAL DESCRIPTION
Its mounting on the downtube allows for discreet integration into the frame, promoting the bike’s balance and a modern design.
Technical Specifications:
Battery brand: Phylion
Part Number: BN21L
Battery type: Battery integrated into the downtube
Technology: Lithium-ion
Nominal voltage: 36 V
Capacity: 630 Wh
Waterproof rating: IPX7
Dimensions: 412 x 62 x 85 mm
Weight: less than 3.2 kg
Mounting location: Frame down tube
Charger: Included
Use: Replacement for the original battery on compatible e-bikes
→ With its high capacity of 630 Wh, this battery allows you to travel long distances while maintaining consistent performance. Its integrated design enhances the bike’s aesthetics and effectively protects the cells from external damage.
Expert Tips:
To maximize the lifespan of your Phylion BN21L battery, use only a compatible charger and avoid repeated deep discharges.
During extended storage, maintain a charge level between 30% and 60% and store the battery in a dry place at a moderate temperature.
