Fischer Joycube SF-06S 48V 14Ah CAN battery
Fischer Joycube SF-06S 48V 14Ah CAN battery
Fischer Joycube SF-06S 48V 14Ah CAN battery
Fischer Joycube SF-06S 48V 14Ah CAN battery
Fischer Joycube SF-06S 48V 14Ah CAN battery
Fischer Joycube SF-06S 48V 14Ah CAN battery
Fischer Joycube SF-06S 48V 14Ah CAN battery
Fischer Joycube SF-06S 48V 14Ah CAN battery

Fischer Joycube SF-06S 48V 14Ah CAN battery

Reference 415300081
Available under 4 weeks
*according to supplier's lead time
Opt for high autonomy and intelligent electronic management with the Fischer Joycube SF-06S 48V 14Ah...
> See more
  • Opt for high autonomy and intelligent electronic management with the Fischer Joycube SF-06S 48V 14Ah CAN - Black battery, specially designed for recent electric bikes equipped with a CAN BUS system.

  • Thanks to its 672 Wh capacity, this battery offers excellent endurance, ideal for both daily commutes and long rides.

  • Positioned on the frame, it guarantees stable, balanced weight integration for enhanced riding comfort.

  • Equipped with a SMART BMS, it ensures optimum communication with the bike, precise energy management and enhanced safety.

  • This battery is intended for Fischer bikes from 2022. To avoid any errors, it is essential to consult the compatibilities below and check the connectors before ordering ↓

  • Scroll down to discover detailed technical specifications and expert advice.

  • Warranty : 2 years
Available under 4 weeks
*according to supplier's lead time
€582.50

The displayed price including VAT is indicative.
The final amount will be calculated based on the delivery address provided when placing the order.

Free delivery from €299

Delivery in 3 to 5 business days
Free for orders over €299

Need help?
Contact one of our experts !

Returns within 14 days

Fischer Joycube SF-06S 48V 14Ah CAN battery
Fischer Joycube SF-06S 48V 14Ah CAN battery
€582.50

Compatibility

  • Fischer |
    Fischer | EM 1922
    Fischer | EM 2127
    Fischer | EM 2129
    Fischer | Montis 2206
    Fischer | Montis EM 1724 / EM 1724.1
    Fischer | Montis EM 1726 / EM 1862.2
    Fischer | Montis Junior
    Fischer | Terra 2.1
    Fischer | Terra Junior
    Fischer | Viator 1.0
    Fischer | Viator 2.0
    Fischer | Viator ETH/ETD 222
    Fischer | Viator ETH/ETD 1861+
    Fischer | Viator ETH/ETD 1861.2
    Fischer | Viator ETH/ETD 2206
Reference 415300081
Available under 4 weeks
*according to supplier's lead time

Technical specifications

Vehicle type
Electric bike
Brand
Fischer
Voltage
48 V
Amperage
14 Ah
Power
672 Wh
Width
80
Height
92 mm
Depth
315 mm
Location
Downtube
Warranty
2 years
Proposed solution
New battery
Ean13
4255775100646

Description

  • Technical data

  • Product type : Battery for electric bike
  • Brand: Joycube
  • Model: SF-06S
  • Manufacturer reference : JCEB480-14.0
  • Nominal voltage: 48 V
  • Capacity: 14 Ah
  • Energy: 672 Wh
  • Position: Frame
  • Color: Black
  • Connections: 6-pin plug
  • Electronic management: SMART BMS with CAN BUS
  • Weight: 3.12 kg
  • Warranty: 2 years

  • Dimensions

  • Width: 80 mm
  • Height: 315 mm
  • Depth: 92 mm

  • This battery is designed to provide a stable, powerful and secure power supply, perfectly suited to modern electric bikes requiring CAN communication between battery and motor system.

  • Recommended compatible charger :

  • 2105036-PHY-V03
  • The use of a suitable charger is essential to guarantee the safety, performance and longevity of the battery.

  • Compatibility

  • Compatible with certain Fischer electric bike models from 2022

  • Doctibike expert advice

  • A 48V battery with CAN BUS requires perfect electronic compatibility: never replace with a non-CAN model.
  • To preserve the cells, avoid repeated full discharges and ideally recharge between 20% and 80%.
  • Store the battery in a dry place, at a moderate temperature, especially when not in use for long periods.
  • SMART BMS protects the battery, but use of the recommended charger is essential to maintain warranty and performance.
